LNK-LBL1 LED LIFEBOAT LIGHT(EXTERNAL)

  • LED light source
  • EC/MED CCS USCG certified
  • Far exceeds SOLAS MSC.81(70) requirements
  • -52℃ polar low temperature endurance
  • External flashing light >4.3cd (actual test up to 20cd)
  • Unique SOLAS reflective tape design
  • Robust modern finishing design
  • 3m cable length or customized as required
SKU: TS-31988 Categories: ,

Description

LNK-LBL1 LED external lifeboat light is a professional signal light for marine lifeboats and rescue boats. It meet the requirements of SOLAS USCG and CCS regulations and obtain relevant certification. The products adopt high-brightness LED light source it also have the advantages of modern appearance durable excellent performance and -52℃ polar low temperature resistance. The product is supplied by DC 12 / 24V power and controled by switch through the input cable. Once activated it will continuously output flashing white light signal with light intensity >4.3cd to indicate the position of lifeboat / rescue boat.

Parameter

Product Lifeboat light
Light source 7* LED
Chromaticity White
Input power DC 12V / 24V
Power ≦5Watt
Function Flashing (50~70 times/min.)
Intensity ≧4.3 cd(Actual- average 20cd)
Water proof IP67
Storing Temperature -52℃ ~ +65℃
Working Temperature -52℃ ~ +65℃
Product Validity 5 Years
Dimension Φ96*90mm
Cable Length 3 meters, accept customized
Weight 280±10g(incl. cable)
Activation Power Switch
Working time >12H
Performance Endure -52℃ low temperature, Fire-resistant, Oil-resistant, Mould-proof, Corrosion-proof, Water-proof, Dust-proof, Resistance UV
Environment Performance Meet RoHS and asbestos-free requirement
Product Standards MSC 81(70) as amended、USCG 161.101、IEC60945:2002 as amended, ISO24408:2004
Certification MED /USCG/CCS
